Opis artikla
Very good speech reproduction; Quick and simple mounting; Very easy to mount; Paintable in all RAL colours; Very low current consumption LED; 3 different power tappings; Lightweight design speaker
Ostale informacije
The CS series loudspeakers are AUDAC’s ceiling
speakers, designed for use any possible application.
The CSW55 is AUDAC’s single cone loudspeaker
with an integrated white signal LED and idle
current control.
The speaker combines professional audio
equipment with great design and comfort.
The ceiling speaker is specially designed to
deliver high-quality speech reproduction, but can
also be used for background music.
The CSE55 is very easy to mount in ceilings
and with the standard white colour housing, the
speaker will not draw any visible attention.
There’s also the oppurtunity to order the CSW55
in any colour from the RAL list, at additional cost.
This way, the CSW55’s installation will be no
issue for all kinds of existing ceilings out there.
The speaker is standard fitted with a 100 Volt line
transformer and connections for different powers:
- 1600 Ohm - 6 W
- 3300 Ohm - 3 W
- 6600 Ohm - 1,5 W
The speaker contains a built-in signal LED which
can be activated with appliance of a 24 V DC.
This LED can be used as a emergency lighting
system for evacuation purposes.
Tehničke specifikacije
| Dimenzije : |
205 x 70 mm |
| Osetljivost (1w/1m) : |
93 dB |
| Težina : |
0,9 kg |
| Frekvencijski opseg (-10dB) : |
|
| Frekvencijski odaziv (-3,+3dB) : |
70 Hz - 14 kHz |
| RMS Snaga : |
15 Watt |
| Max snaga : |
20 Watt |
| Max SPL : |
109 dB |
| Impendansa : |
8 Ohm |
