Opis artikla
High output 3-way active driven system; Horn loaded system; 750 Watt RMS Power; Multifunctional carry handles for easy handling; Metal frame for safe & easy rigging; 90° x 40° Rotatable horn; 18 mm solid plywood enclosure construction
Ostale informacije
The FX3.15 is a 3-Way high-output, active driven
compact High / Mid / Mid-Bass speaker cabinet
which is a part of the unique and versatile FX series
system.
In combination with the FX1.18 bass cabinet available
in the FX series, this truly modular system can
be scaled and adapted for every application where a
powerful system with a high clarity and sound quality
is required.
This three-way cabinet includes a 15” horn-loaded
Mid-Bass driver, 6” loaded mid speaker and 1.75”
PEEK (Polyether ether ketone) compression driver.
The entire system has a power handling of 750 Watt
RMS with a maximum power of 1500 Watt. The MidBass
section takes part for 500 Watt RMS while the
Mid section takes part for 200 Watt RMS and the
High section represents 50 Watt RMS.
The horn with a coverage pattern of 90° x 40° incorporates
both High and Mid frequency drivers which
can be rotated allowing complete flexibility in selection
of horizontal & vertical as well as left & right
positioning.
This system shall be active processed and powered
by separate amplifiers for each section. The connections
for each sections are performed using two
8-pin speakon compatible connectors, allowing linkthrough
when multiple identical speakers are used
in the same system.
The compact enclosure is provided with weatherproof
and scratch resistant Dura Coat textured
paintwork and is fitted with eight carry handles allowing
easy carriage and handling of the system.
The integrated metal rigging frame allows easy
and secure rigging, allowing multiple cabinets to be
rigged together.
Tehničke specifikacije
Dimenzije : |
714 x 456 x 580 mm |
Osetljivost (1w/1m) : |
105 dB |
Težina : |
47,5 kg |
Frekvencijski opseg (-10dB) : |
85 Hz - 20 kHz |
Frekvencijski odaziv (-3,+3dB) : |
130 Hz - 20 kHz |
RMS Snaga : |
750 Watt |
Max snaga : |
1500 Watt |
Max SPL : |
|
Impendansa : |
8 Ohm |
