Opis artikla
High-quality in-wall/ceiling loudspeaker; 5 1 ” 2-Way driver; Fast-con™ connections; 100V multitap transformer & 8 Ohm bypass; Moisture proof cone treatment; Aluminum front grill; Wide 100° conical coverage; Quick-fit installation system; Paintable to blend-in
Ostale informacije
The WS series loudspeakers are high-quality inwall/ceiling
loudspeakers, delivering exceptional
sound quality and value for a wide variation of
applications, ranging from paging and announcements
to background music systems in a wide
range of business applications, including hotels,
restaurants and pubs, corporate offices, retail
stores, etc.
The WS524 in-wall/ceiling loudspeaker features a
5 1 ” driver with a coaxially mounted 1” tweeter,
having a continuous power handling of 30 Watt
and a maximum power handling of 60 Watt. The
2-way construction makes the WS524 the perfect
match for a wide variation highly demanding
of applications, guaranteeing a high-quality and
true-to-nature reproduction of music and speech.
The moisture proof treatment on the speakers’
cone and aluminum front grill protects it for installation
in humid or outdoor environments.
A multi-tapping line transformer fitted with Fastcon™
allows fast and smooth connections to 100
Volt public address or low impedance systems.
The mounting of the loudspeaker into the wall or
ceiling is achieved with a Quick-fix mechanism,
offering a great installers convenience and lifetime
stability.
The construction of the speakers’ housing is made
out of high-quality ABS, while the front is covered
by a solid powder-coated aluminum grille. Custom
painting is possible for a total blending into
any environment.
Tehničke specifikacije
| Dimenzije : |
|
| Osetljivost (1w/1m) : |
|
| Težina : |
|
| Frekvencijski opseg (-10dB) : |
|
| Frekvencijski odaziv (-3,+3dB) : |
|
| RMS Snaga : |
|
| Max snaga : |
|
| Max SPL : |
|
| Impendansa : |
|
