Opis artikla
High-quality ceiling loudspeaker; 8” 2-way driver; Fast-con™ connections; 100V multitap transformer & 8 Ohm bypass; Moisture proof cone treatment; Aluminium front grill; Wide 130° conical coverage; Quick-fit installation system; Paintable to blend-in
Ostale informacije
The CS series loudspeakers are high-quality
in-ceiling loudspeakers, delivering exceptional
sound quality and value for a wide variation
of applications, ranging from paging and
announcements to background music systems in
a wide range of business applications, including
hotels, restaurants and pubs, corporate offices,
retail stores, etc.
The CS85 in-ceiling loudspeaker features a 8”
driver with a coaxially mounted 1” tweeter, having
a continuous power handling of 40 Watt and a
maximum power handling of 80 Watt. The 2-way
construction makes the CS85 the perfect match for
a wide variation highly demanding of applications,
guaranteeing a high-quality reproduction of music
and speech with true and deep performance in
the low frequency range. This guarantees a true
Hi-Fi experience.
The moisture proof treatment on the speakers’
cone and aluminium front grill protects it for
installation in humid or outdoor environments.
A multi-tapping line transformer fitted with Fastcon™
allows fast and smooth connections to 100
Volt public address or low impedance systems.
The mounting of the loudspeaker into the ceiling
is achieved with a Quick-fix mechanism, offering a
great installers convenience and lifetime stability.
The construction of the speakers’ housing is
made out of high-quality ABS, while the front is
covered by a solid powder-coated aluminium
grille. It comes available in different colours, while
custom painting is possible for a total blending
into any environment.
Tehničke specifikacije
Dimenzije : |
275 x 90 mm |
Osetljivost (1w/1m) : |
94 dB |
Težina : |
2 kg |
Frekvencijski opseg (-10dB) : |
35 Hz - 20 kHz |
Frekvencijski odaziv (-3,+3dB) : |
40 Hz - 20 kHz |
RMS Snaga : |
40 Watt |
Max snaga : |
80 Watt |
Max SPL : |
112 dB |
Impendansa : |
8 Ohm |
